Factors Affecting TOD Potential |
Highly Supportive
of TOD
( ) |
Somewhat Supportive
of TOD
( ) |
Not Supportive
of TOD
( ) |
Pedestrian Environment |
Area has sidewalks throughout, pedestrian amenities, and development along the streetscape edge |
Area has sidewalks throughout and moderate setbacks with limited parking |
Area has no sidewalks or limited sidewalks; development has large setbacks with large parking lots |
Current and Planned Transit Services |
The site is served by several existing bus/rail routes and planned short-term rail or bus rapid transit |
The site is served by several existing bus/rail routes and planned long-term rail or bus rapid transit |
The site is served by only a few existing bus routes |
Mix of Land Uses |
The site includes a mix of housing, retail commercial, and employment uses |
The site includes a mix of housing and retail commercial |
The site is predominately a single land use type |
Existing Population Densities |
Zone(s) of population in the area already meet or exceed 18.5 persons per acre typical for TOD |
Zone(s) of population in the area are between 9.5 and 18.5 persons per acre approaching typical levels for TOD |
Zone(s) of population in the area are less than 9.5 persons per acre, substantially less than is typical for TOD |
Existing Employment Densities |
Zone(s) of employment in the area already meet or exceed 25 employees per acre typical for TOD |
Zone(s) of employment in the area are between 12.5 and 25 employees per acre approaching typical levels for TOD |
Zone(s) of employment in the area are less than 12.5 employees per acre, substantially less than is typical for TOD |
Available or Underutilized Properties for Development |
The area has visible vacant properties or buildings |
The area has visible commercial developments that are partially vacant or have underutilized parking |
The area has few or no visible vacant, partially vacant, or underutilized properties |
Recent Development Activity |
The area has visible multifamily residential, office, or street edge commercial development that is under construction or has recently been constructed |
The area has visible development that is under construction or has been recently constructed |
The area has no visible development that is under construction or has been recently constructed |
The West Dade Transit Hub is located along S.R. 836 (Dolphin Expressway) at the 107th Street interchange. The Miami International Mall is located about one-half-mile north of the interchange. The area along NW 107th Street adjacent to the mall includes retail strip commercial development and two mid-rise office buildings located on the west side of the street near the entrance to the mall. The mall is surrounded by large surface parking lots served by a ring road. The area adjacent to the mall includes automobile-oriented retail strip commercial development with moderate to large building setbacks and surface parking. The area is currently served by bus routes 7, 71, East-West Connection, Doral Connection, and West Dade Connection, and is located along the planned East-West Corridor Metro Rail Extension. Household densities north of S.R. 836 are generally low, with most residential concentrated in the area along NW 107th Street south of S.R. 836. Here, household densities exceed 7.0 households per acre. Employment densities for the zone that includes the Miami International Mall exceed 25 employees per acre. A large vacant undeveloped parcel is located on the northwest corner of NW 107th Street and S.R. 836. One department store within the mall is vacant. The area along the south edge of the site includes some recently constructed retail commercial development. This development is also auto-oriented, with moderate setbacks and surface parking.
