Considerations in Assessing the TOD Potential of Intermodal Center Sites

Factors Affecting TOD Potential

Highly Supportive
of TOD
( )

Somewhat Supportive
of TOD
( )

Not Supportive
of TOD
( )

Pedestrian Environment

Area has sidewalks throughout, pedestrian amenities, and development along the streetscape edge

Area has sidewalks throughout and moderate setbacks with limited parking

Area has no sidewalks or limited sidewalks; development has large setbacks with large parking lots

Current and Planned Transit Services

The site is served by several existing bus/rail routes and planned short-term rail or bus rapid transit

The site is served by several existing bus/rail routes and planned long-term rail or bus rapid transit

The site is served by only a few existing bus routes

Mix of Land Uses

The site includes a mix of housing, retail commercial, and employment uses

The site includes a mix of housing and retail commercial

The site is predominately a single land use type

Existing Population Densities

Zone(s) of population in the area already meet or exceed 18.5 persons per acre typical for TOD

Zone(s) of population in the area are between 9.5 and 18.5 persons per acre approaching typical levels for TOD

Zone(s) of population in the area are less than 9.5 persons per acre, substantially less than is typical for TOD

Existing Employment Densities

Zone(s) of employment in the area already meet or exceed 25 employees per acre typical for TOD

Zone(s) of employment in the area are between 12.5 and 25 employees per acre approaching typical levels for TOD

Zone(s) of employment in the area are less than 12.5 employees per acre, substantially less than is typical for TOD

Available or Underutilized Properties for Development

The area has visible vacant properties or buildings

The area has visible commercial developments that are partially vacant or have underutilized parking

The area has few or no visible vacant, partially vacant, or underutilized properties

Recent Development Activity

The area has visible multifamily residential, office, or street edge commercial development that is under construction or has recently been constructed

The area has visible development that is under construction or has been recently constructed

The area has no visible development that is under construction or has been recently constructed

Site Area Description

This site is located near the intersection of Red Road and NW 158th Street, directly adjacent to the Miami Lakes Technical Education Center. Development in the area is characterized by large setbacks with surface parking lots. Educational facilities and business park development predominate, with some retail strip commercial development on the east side of Red Road between 159th Street and the Palmetto Expressway. The area is served by bus routes 29, 73, 75, 95, and North Dade Connection, but is not located along any of the planned rapid transit corridors. A large canal runs along the west side of Red Road, restricting pedestrian access to properties along that side of the roadway. Household density is generally very low, in the range of 3.5 to 7.0 households per acre. Employment densities are relatively higher, exceeding 25 employees per acre in the zone located at the southwestern corner of Red Road and the Palmetto Expressway. There are a few vacant parcels on the west side of Red Road just south of the Expressway, but no current development activities are visible in the area.

Potential of Existing Miami Lakes Technical Education Center Area to Support Transit-Oriented Development

Factors Affecting Transit-Oriented Development

Rating for Intermodal Site

Pedestrian Environment

Not Supportive

Current and Planned Transit Services

Not Supportive

Mix of Land Uses

Not Supportive

Household Densities

Not Supportive

Employment Densities

Somewhat Supportive

Available or Underutilized Properties for Development

Highly Supportive

Ongoing Development Activity

Not Supportive
